Die-cast Aluminum P1.5mm HD LED Display Extremely Light and Slim
MI-P series P1.5625mm Die-casting Aluminum LED Display screen Quick Details:
- 60X337.5mm Cabinet Standard Size
Exremely light and slim, only 7kg weight and 48mm thickness
- SMD 3 in 1 LED Encapsulation technology
Sper wide viewing angle with long lisespan
- 2K 4K HD Video Quality
High definition video quality brings amazing visual feast, and a
perfect embodiment of the new generation of ultra high definition
led display technology.
- Wide color gamut +HDR
High color coverage, precise reproduction of natural colors, making
the picture more realistic
HDR can reproduce the high peak of High dynamic range imaging and
display more details
- LED Module, Power supply, cards front maintenance
Save Installation and mainteance space
- Support GOB tech, Glue on Board
Dust proof, waterproof and collision resistant
- Seamless Splicing
Die-casting Alumium Cabinet sctructure with CNC high-precision
processing,Flatness of Cabinet≤0.1mm
- Support Dual-backup design of power supply and receive
card(signal)
- Application
Welcome using in conference room, schools, office, malls,
restaurant and other field indoor places
Parameters:
| Pixel pitch | mm | 1.5625 |
| Brightness | nits | >=600 |
| Color temperature | deg.k | 2000 ~ 9500 |
| Viewing angle - Horizontal | deg. | 170(+85/-85) |
| Viewing angle - Vertical | deg. | 170(+85/-85) |
| Cabinet weight | kg | 7 |
| Cabinet width | mm | 600 |
| Cabinet height | mm | 337.5 |
| Cabinet depth | mm | 48 |
| Cabinet material | | Die-cast Aluminum |
| Operating temperature range | deg. C | -20 to 60 |
| Operating humidity range | HR | 10％ to 85％ |
| Pixel type and configuration | R/G/B | SMD1010/1212 |
| Pixel matrix per cabinet | dots | 384X216 |
| LED module size(WXH) | mm | 300X168.75 |
| Module resolution(WXH) | dots | 192X108 |
| Gray scale | Levels | 65536 levels per colour |
| Brightness control | Levels | 100 |
| Frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 3840 |
| Input voltage | VAC | 110/240 |
| Input power frequency | Hertz | 50/60 |
| Power (max/avg) | Watts per sq.m | 450/150 |
| Grey scale level | bits | 16 |
