Smd Indoor Stage Rental Led Display Ultra Thin Panel P2.6 P2.9 P3.9
P4.8
Application:
Di-YD series Stage Rental LED Displays are usually used for stage
background of live shows, advertising and broadcasting in museum,
theater, opera house, church, concert hall, bars and so on.
Di-YD Stage Rental LED Displays include indoor rental led screen:
2.604mm, 2.976mm, 3.91mm, 4.81mm, 5.9mm best-selling types.
Features and Details:
- Pixel Pitch: 2.604mm, 2.976mm, 3.91mm, 4.81mm, SMD LEDs.
- Full colors: 281trillions.
- Wide viewing angle: 160°/ 160°.
- Standard cabinet size: 500×500x80mm, 500x1000x80mm.
- Die-casting aluminium, ultra lightweight and thin, only 7-7.5kg
for 500x500mm panel and 13-14kg for 500x1000mm panel, thickness is
only 8cm, can be lifted with only one hand.
- Fast assembling and easy installation with handle and fast lock
design.
- Seamless connection, each cabinet flatness only 0.01mm.
- High definition, high refresh rate 1,920Hz and 16bits gray scale,
give you more colorful video and image.
Parameters:
| Model | Di-YD2.6 | Di-YD2.9 | Di-YD3.9 | Di-YD4.8 |
| Pixel Pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 147,456 pixels/m2 | 112,896 pixels/m2 | 65,536 pixels/m2 | 43,264 pixels/m2 |
| Module Dimensions (W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 500 x 80 | 500 x 500 x 80 | 500 x 500 x 80 | 500 x 500 x 80 |
| Modules Per Cabinet (W x H) | 2 x 2 | 2 x 2 | 2 x 2 | 2 x 2 |
| Module Resolution | 96 x 96 | 84 x 84 | 64 x 64 | 52 x 52 |
| Cabinet Resolution | 192 x 192 | 168 x 168 | 128 x 128 | 104 x 104 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 7.5kg | 7.5kg | 7.5kg | 7.5kg |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm |
| Max Power Consumption | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm |
| Brightness | >1,000 nits | >1,000 nits | >1,000 nits | >1,000 nits |
| Refresh Rate | >3,840Hz | >3,840Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating (Front/Rear) | IP 43 | IP 43 | IP 43 | IP 43 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
After-sales services:
1). We provide customer service through whatsapp, phone or email,
supply you video or drawing to solve problems.
2). We provide remote control service through internet to achieve
real time service, which will short time of solving problems.
3). We provide professional engineer one-to-one to keep fast reply.
Best After-sale Service
If your LED display is defected and is in warranty period, we offer
you free accessories for the product. Whenever you need us, we are
always there for you. Our support staff is more than willing to
assist you for any query or concern. Feel free to contact us any
time
Installation Service:
1). We provide detailed CAD drawing to customer for preparing metal
structure.
2). We could dispatch our engineer to your place , guide
installation and free training.
3). Special designs have special solutions; we will make perfect
solutions to satisfy all customers' requirements.
