Waterproof Outdoor Rental LED Display P2.6mm P2.9mm 500X1000mm LED
Panel
Feature Of Outdoor 500x1000 Rental LED Screen
- Ultra-light - weight only 15kg, one people can carry, quick
installation
- With fast lock design, 500x500mm and 500x1000mm cabinet can be
easily spclied up and down, and mixed use.
- Reinforced connection design, all connection part is strong and
reliable for all kinds of application.
- High precision, with high end CNC machine, the allowance is as
small as within 0.1mm, which keeps the screen in perfect flat
surface and create smooth image performance.
- Packing, with strong and high end flight cases, 8 in 1 or 6 in 1
as customer demand.
Parameters:
| Model | D-LT2.6 | D-LT2.9 | D-LT3.9 | D-LT4.8 |
| Pixel Pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 147,456 pixels/m2 | 112,896 pixels/m2 | 65,536 pixels/m2 | 43,264 pixels/m2 |
| Module Dimensions (W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 1000 x 80 | 500 x 1000 x 80 | 500 x 1000 x 80 | 500 x 1000 x 80 |
| Modules Per Cabinet (W x H) | 2 x 4 | 2 x 4 | 2 x 4 | 2 x 4 |
| Module Resolution | 96 x 96 | 84 x 84 | 64 x 64 | 52 x 52 |
| Cabinet Resolution | 192 x 384 | 168 x 336 | 128 x 256 | 104 x 208 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 15kg | 15kg | 15kg | 15kg |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 280 W /Sqm | 260 W /Sqm | 250 W /Sqm | 220 W /Sqm |
| Max Power Consumption | 680 W /Sqm | 650 W /Sqm | 620 W /Sqm | 600 W /Sqm |
| Brightness | >5,000 nits | >5,000 nits | >5,000 nits | >5,000 nits |
| Refresh Rate | >3,840Hz | >3,840Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating (Front/Rear) | IP 65 | IP 65 | IP 65 | IP 65 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
Our Services
1. 15 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to
customer request
3. Wholesale price
4. OEM and ODM service
5. CE, ROHS, FCC, ETL, TUV certified supplier
FAQ:
Q1. What's fast delivery time?
The production can be controlled as fast as you need from 7 days to
25 days.
Q2. Can I just wait for the items at my door and no need to do
others?
Yes, items can be delivery to your specific address and you just
wait for receiving the items at your door and nothing to do.
Q3. The display will come to me in parts?and i have to install each
part together?
Yes, but it's quite easy. We will send you the instruction and also
we can remote to help you to adjust the software, everything.
Q4. What's the function of video processor?
It can transfer the video source to make the screen performance
more clear. Sometimes there has HD camera, so that the performance
can show themselves on the screen as well.
Q5. How can I install the led display?
There are two options, one is hanging the display, the other is
standing the display. Hanging bars and back stacking will be
provided.
