500x1000mm Outdoor Rental LED Screen P2.6 P2.9 With 3840Hz Refresh
Rate
500x1000mm Die Cast Aluminum Outdoor Rental LED Display With 3840Hz
Refresh Rate
Application Of Outdoor Rental LED Display
In addition to the selection of the screen body, the LED stage
screen also needs to select a suitable control system. In general,
the LED stage screen has a large area and high pixels, which
requires a high number of sending cassettes, and sometimes requires
multiple control cards for cascade splicing control. If the display
effect is better, we usually need to use the video processor, which
can splice and cut the video to achieve multi-window,
picture-in-picture, strong scalability, and more delicate and
smooth video effect. n Due to the particularity of LED rental stage
screen, it generally adopts standardized box structure, which is
easy to disassemble and assemble, light in weight and convenient in
transportation. The box body is light and thin, can be quickly
installed, removed and transported, and is suitable for large-area
rental and fixed installation application places. Finally, it is
necessary to provide professional training for operators, so that
they can carry out basic maintenance of the display screen, such as
analysis and treatment of common faults, familiarity with the
control system and video processing, and detection and adjustment
of the corresponding supporting equipment, so as to ensure the
stable and safe operation of the LED stage screen.
Feature Of Outdoor Rental LED Display
Conwin LED outdoor rental led screen include P2.9mm, 3.91mm and
P4.81mm Features are:
- Adjustable Angle lock for curve Application via Rotary Lock
- Advanced Flash Function: The Calibration Data can be Saved to the
receiver card and used automatically
- Outdoor Waterproof IP65 Standard, Front and Rear Maintenance via
Magnets
- Rubber seal for the back of the module, to create maximum
protection against rain or moisture
- Easy to use corner protectors, push it and corner protector
released
Parameters:
| Model | D-XK2.6 | D-XK2.9 | D-XK3.9 | D-XK4.8 |
| Pixel Pitch | 2.604mm | 2.976mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 147,456 pixels/m2 | 112,896 pixels/m2 | 65,536 pixels/m2 | 43,264 pixels/m2 |
| Module Dimensions(W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 1000 x 80 | 500 x 1000 x 80 | 500 x 1000 x 80 | 500 x 1000 x 80 |
| Modules Per Cabinet (W x H) | 2 x 4 | 2 x 4 | 2 x 4 | 2 x 4 |
| Module Resolution | 96 x 96 | 84 x 84 | 64 x 64 | 52 x 52 |
| Cabinet Resolution | 192 x 384 | 168 x 336 | 128 x 256 | 104 x 208 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 15kg | 15kg | 15kg | 15kg |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 280 W /Sqm | 260 W /Sqm | 250 W /Sqm | 220 W /Sqm |
| Max Power Consumption | 680 W /Sqm | 650 W /Sqm | 620 W /Sqm | 600 W /Sqm |
| Brightness | >5,000 nits | >5,000 nits | >5,000 nits | >5,000 nits |
| Refresh Rate | >3,840Hz | >3,840Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating (Front/Rear) | IP 65 | IP 65 | IP 65 | IP 65 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
Our Services
1. 20 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to
customer request
3. Wholesale price
4. OEM and ODM service
5. Customizable product upon request
A: We provide 1-3 years warranty for different products. Free
Repair or Exchange of Defective Parts with One-way Shipping
