P2.604mm P2.976mm Stage Rental LED Display Concert Party Video Wall

Ask Lasest Price
Brand Name :	Conwin LED Display
Model Number :	D-XF2.6, D-XF2.9
Certification :	FCC, CE, ROHS
Price :	Negotiable
Payment Terms :	T/T, L/C
Supply Ability :	1000 sqm per month
Delivery Time :	15 working days

Add to Cart

Product Details
Company Profile

P2.604mm P2.976mm Stage Rental LED Display Concert Party Video Wall

Quick Detais

- Pixel Pitch: 2.604mm. 2.976mm
- Quality and High Contrast SMD LEDs, Wide viewing angle: 160°/ 160°.
- Greyscale: 14-16bits with NOVA Star
- Cabinet size: 500x1000mm Die Cast Aluminum
- Recommended Min Viewing Distance: 2-3m.

- Cabinet Material: Die Cast Aluminum Cabinet,15kg Weight

- Refresh Rate: 3840Hz

- Ingress Rate: IP65 Outdoor

- Quality Certificate:CE, RoHS,FCC, ETL

- Brightness:>5000cd/sqm

- Curve Installation: Yes, Concave and Convex Available

- Corner Protector: Available
Die Cast aluminum light weight Structure

Outdoor Rental Series is designed to meet the requirements of a wide range of applications. Through thoughtful engineering and craftsmanship, the Outdoor Rental ⅠSeries features a thin, lightweight, high-strength die-casting in a modular design to fit a wide range of simple or complex applications. The unique structural design of Outdoor Rental has pioneered, patented and perfected the use of die-casting in the construction of LED video wall displays.

Seamless screen splicing and Support ±15 degree installation

It has the following advantages: Arc shaped panel edge,seamless splicing and no angle acquirement,perfect arc-bending panel technology vivid visual effects and no distorition.Double-side 15 degree oblique angle design,support ±15 degree assembly,Sticky tape support seamless connection between panels.

Parameters:

Model	D-XF2.6	D-XF2.9	D-XF3.9	D-XF4.8
Pixel Pitch	2.604mm	2.976mm	3.91mm	4.81mm
Pixel Configuration	SMD1415	SMD1415	SMD1921	SMD1921
Pixel Density	147,456 pixels/m2	112,896 pixels/m2	65,536 pixels/m2	43,264 pixels/m2
Module Dimensions (W x H) (mm)	250 x 250	250 x 250	250 x 250	250 x 250
Panel Dimensions (mm)	500 x 1000 x 80	500 x 1000 x 80	500 x 1000 x 80	500 x 1000 x 80
Modules Per Cabinet (W x H)	2 x 4	2 x 4	2 x 4	2 x 4
Module Resolution	96 x 96	84 x 84	64 x 64	52 x 52
Cabinet Resolution	192 x 384	168 x 336	128 x 256	104 x 208
Panel Material	Die Cast Aluminum	Die Cast Aluminum	Die Cast Aluminum	Die Cast Aluminum
Weight per Cabinet	15kg	15kg	15kg	15kg
Colours	281 trillion	281 trillion	281 trillion	281 trillion
Contrast Ratio	5,000 : 1	5,000 : 1	5,000 : 1	5,000 : 1
Average Power Consumption	280 W /Sqm	280 W /Sqm	280 W /Sqm	280 W /Sqm
Max Power Consumption	800 W /Sqm	800 W /Sqm	800 W /Sqm	800 W /Sqm
Brightness	>5,000 nits	>5,000 nits	>5,000 nits	>5,000 nits
Refresh Rate	>3,840Hz	>3,840Hz	>3,840 Hz	>3,840 Hz
Vertical Viewing Angle	160°	160°	160°	160°
Horizontal Viewing Angle	160°	160°	160°	160°
Expected Lifetime	100,000 Hrs	100,000 Hrs	100,000 Hrs	100,000 Hrs
Servicing	Front/Rear	Front/Rear	Front/Rear	Front/Rear
IP Rating (Front/Rear)	IP 65	IP 65	IP 65	IP 65
Operating Temp/Humidity	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%
Storage Temp/Humidity	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%

Pictures:
