P2.9mm P3 Outdoor Advertising LED Display IP65 Weatherproof For
Billboard
Front Service Outdoor LED Display LED Billboard , 1X1m LED cabinet
for outdoor ads using
Most frequent used outdoor led video wall product in the market,
annual sales over 20,000 sqm. High Visibility, high clarify and
smart cabinet design making it the perfect choice for outdoor
advertising.
Features and Advantages:
- Smart Cabinet Design
IP65 Ingress rate for extreme weather protection
Cold rolled steel with extra powder coating for anti-rust
Side handle convienent design for easy installation
- High Visibility
Brighter even when in sunny days
High color uniformity and consistence
High definition and contrast
- High Clarity SMD Technology
Closer viewing distance
Wider viewing angle
Front or rear serviceable
- LED Module size 250X250 front service
- IP rating: front: IP65/ rear: IP54, waterproof
- Input voltage: 110V/220V AC, 50/60Hz
- Recommended minimum viewing distance: 6m,8m
- Steel cabinet or Aluminum cabinet
- Power ,signal plug choosed
- Cabinet size customized according to LED module size 250X250mm
Regular size 1000X1000mm, other size
1000X750mm,1000X500mm,1250X1000mm....
- Cabinet Design
- Cabinet Design with Plug
Parameters:
| Model | E-C2.9 |
| Pixel Pitch | 2.976mm |
| Pixel Configuration | SMD1515 |
| Pixel Density | 112896 pixels/m2 |
| Module Dimensions(W x H)(mm) | 250 x 250 |
| Panel Dimensions (mm) | 1000 x 1000 x 150 |
| Modules Per Cabinet (W x H) | 4 x 4 |
| Module Resolution | 84 x 84 |
| Cabinet Resolution | 336 x 336 |
| Panel Material | Cold steel |
| Weight per Cabinet | 44kgs |
| Colors | 281 trillion |
| Contrast Ratio | 5,000 : 1 |
| Average Power Consumption | 300 W /Sqm |
| Max Power Consumption | 900 W /Sqm |
| Brightness | >5,000 nits |
| Refresh Rate | >3,840Hz |
| Vertical Viewing Angle | 160° |
| Horizontal Viewing Angle | 160° |
| Expected Lifetime | 100,000 Hrs |
| Servicing | Front / Rear |
| IP Rating (Front/Rear) | IP65 / IP54 |
| Operating Temp/Humidity | -20ºC - 50ºC /
10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC /
10% - 90% |
Pictures:
Our Services
1. 20 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to
customer request
3. Wholesale price
4. OEM and ODM service
5. Customizable product upon request
