High Brightness HD P2 P2.5mm Outdoor LED Display Fine Pitch LED Cabinet

Ask Lasest Price
Brand Name :	Conwin LED Display
Model Number :	E-M2.5
Certification :	FCC, CE, ROHS
Price :	Negotiable
Payment Terms :	T/T, L/C
Supply Ability :	1,000 sqm per month
Delivery Time :	15days

Add to Cart

Product Details
Company Profile

High Brightness HD P2 P2.5mm Outdoor LED Display Fine Pitch LED Cabinet

High Definition Led Display Screen For Advertising

Application Of Outdoor LED Advertising Display

The front turning screen has the characteristics of convenient installation, light weight, capability of being hung on a wall and capable of being hoisted against the wall. The whole display screen can be made thin, which is very suitable for display screen settings in some special places. The products are mainly used in information announcements, image advertisements, activity advertisements, etc. Its advantage is to save the trouble of removing the whole screen when there is no maintenance space on the back, and its disadvantage is that the connection part of the two boxes needs several times more power lines and flat cables than the ordinary box. And the information content on the display screen can be changed at any time to display different information and advertisements for different customers all day long. The high-efficiency optical fiber transmission system effectively reduces the signal delay caused by long transmission distance and ensures the consistency of picture playing. It is believed that with the increasing segmentation of the display market demand, the demand for front maintenance LED display (LED front flip screen) is also increasing.

Quick Details

- Pixel Pitch: 2.5mm
- Cabinet size: 960x960mm Aluminum Cabinet
- Recommended Viewing Distance: 2.5m

- Refresh Rate: 3840Hz

- Ingress Rate: IP65 Outdoor Standard

- LED Module size 320X160mm

Parameters:

Model	E-M2.5	E-M3
Pixel Pitch	2.5mm	3.0769mm
Pixel Configuration	SMD1415	SMD1921
Pixel Density	160000 pixels/m2	105625 pixels/m2
Module Dimensions(W x H)(mm)	320 x 160	320 x 160
Panel Dimensions (mm)	960 x960 x 120	960 x960 x 120
Modules Per Cabinet (W x H)	3 x 6	3 x 6
Module Resolution	128 x 128	104 x 104
Cabinet Resolution	384 x 384	312 x 312
Panel Material	Aluminum	Aluminum
Weight per Cabinet	33kgs	33kgs
Colors	281 trillion	281 trillion
Contrast Ratio	5,000 : 1	5,000 : 1
Average Power Consumption	330 W /Sqm	330 W /Sqm
Max Power Consumption	950 W /Sqm	950 W /Sqm
Brightness	>6,000 nits	>6,000 nits
Refresh Rate	>3,840Hz	>3,840Hz
Vertical Viewing Angle	160°	160°
Horizontal Viewing Angle	160°	160°
Expected Lifetime	100,000 Hrs	100,000 Hrs
Servicing	Rear	Rear
IP Rating (Front/Rear)	IP65 / IP54	IP65 / IP54
Operating Temp/Humidity	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%
Storage Temp/Humidity	-20ºC - 50ºC / 10% - 90%	-20ºC - 50ºC / 10% - 90%

Pictures:

Our Services

1. 20 Years professional led display manufacturer

2. Short delivery time: 5-15 working days, adjustable according to customer request
3. Wholesale price

4. OEM and ODM service
5. Customizable product upon request
