Permanent Install Indoor LED Video Wall 320X160mm LED Module Panel 3840Hz

Ask Lasest Price
Brand Name :	Conwin LED Display
Model Number :	Ei-A Series
Certification :	CE-EMC, CE-LVD, RoHS, ETL, FCC
Payment Terms :	T/T, L/C
Supply Ability :	1,000sqm/month
Delivery Time :	15days
Price :	Negotiable

Add to Cart

Product Details
Company Profile

Permanent Install Indoor LED Video Wall 320X160mm LED Module Panel 3840Hz

Indoor Permanent Install LED Display LED Video Wall 320X160mm LED Module

High Resolution Indoor Full Color Led Display Advertising Led Video Wall

Indoor Fixed LED Display Screen

Application:

Indoor Ei-A Series is mainly used in enterprises, institutions, sports venues, the ticket hall, hotels, securities companies, schools, stage, public security, shopping centers and other fields.

Features and Advantages:

- Support HD 2K 4K Video Capability, bring you absolute visual experience

- Multiple Creative Application Available

- Apply for Various Location

Can be used as the indoor stage Led display, dance floor, stadium LED display, sky backdrop curtain, fixing advertising LED display, showcase LED display, etc.

- Simple and Fast installation

- Pixel Pitch:P2mm P2.5mm, P3.076mm, P4mm and P5mm
- Brand SMD LEDs, high contrast and high reliability
- Greyscale: 14-16bits
- Cabinet size: Could be customized according to led module size 320X160mm
- Service type: Magnetic front service

- Refresh Rate: 3840Hz

- Brightness: >600nits

- Wide View angle 160/160 H/V

- LED Module Size 320X160mm, support magnetic front service

Economic Steel Fixed Indoor LED Video Wall 320X160mm LED Module 0

Economic Steel Fixed Indoor LED Video Wall 320X160mm LED Module 1

- Different Cabinet design ,could be customized according to required.

Major economic cabinet design with below design

1. Simple cabinet without rear door(size could be different according to LED Module size 320X160mm)

Economic Steel Fixed Indoor LED Video Wall 320X160mm LED Module 2

Economic Steel Fixed Indoor LED Video Wall 320X160mm LED Module 3

2. Cabinet without rear door(size could be different according to LED Module size 320X160mm)

Rear door design could be customized. Steel cabinet or aluminum cabinet could be choosed.

Also for the power/signal plug could be design or added

Economic Steel Fixed Indoor LED Video Wall 320X160mm LED Module 6

Economic Steel Fixed Indoor LED Video Wall 320X160mm LED Module 7

- High refresh, High grey scale and High contast ratio, Ultimate visual enjoyment

- Different Installation type supported

GOB HOB LED Display Video Wall P1.667mm P1.839mm P1.86mm 5

Parameters:

Model	Ei-A2	Ei-A2.5	Ei-A3	Ei-A4	Ei-A5
Pixel Pitch	2mm	2.5mm	3.0769mm	4mm	5mm
Pixel Configuration	SMD1515	SMD2121	SMD2121	SMD2121	SMD2121
Pixel Density	250000 pixels/m2	160000 pixels/m2	105625 pixels/m2	62500 pixels/m2	40000 pixels/m2
Module Dimensions (W x H)(mm)	320 x 160	320 x 160	320 x 160	320 x 160	320 x 160
Module Resolution	160 x 80	128 x 64	104 x 52	80 x 40	64 x 32
Colors	281 trillion	281 trillion	281 trillion	281 trillion	281 trillion
Contrast Ratio	5,000 : 1	5,000 : 1	5,000 : 1	5,000 : 1	5,000 : 1
Average Power Consumption	210 W /Sqm	210 W /Sqm	210 W /Sqm	210 W /Sqm	210 W /Sqm
Max Power Consumption	600 W /Sqm	600 W /Sqm	600 W /Sqm	600 W /Sqm	600 W /Sqm
Brightness	>600 nits	>600 nits	>600 nits	>600 nits	>600 nits
Refresh Rate	>3,840Hz	>3,840Hz	>3,840Hz	>3,840Hz	>3,840Hz
Vertical Viewing Angle	160°	160°	160°	160°	160°
Horizontal Viewing Angle	160°	160°	160°	160°	160°
Expected Lifetime	100,000 Hrs	100,000 Hrs	100,000 Hrs	100,000 Hrs	100,000 Hrs
Servicing	Front	Front	Front	Front	Front
IP Rating (Front/Rear)	IP43 / IP21	IP43 / IP21	IP43 / IP21	IP43 / IP21	IP43 / IP21

Pictures:

Our Services

1. 20 Years professional led display manufacturer

2. Short delivery time: 5-15 working days, adjustable according to customer request
3. Wholesale price

4. OEM and ODM service
5. Customizable product upon request
