Indoor Transparent LED Display Screen 1000X1000mm 500X1000mm

Ask Lasest Price
Brand Name :	Conwin LED Display
Model Number :	T-B Series
Certification :	FCC, CE, ROHS
Price :	Negotiable
Payment Terms :	T/T, L/C
Supply Ability :	1,000 sqm per month
Delivery Time :	15 days

Add to Cart

Product Details
Company Profile

Indoor Transparent LED Display Screen 1000X1000mm 500X1000mm

Indoor Transparent LED Display Screen 1000X1000mm 500X1000mm LED Display Panel

Indoor Crystal Transparent LED Display LED Screen

Features and Details

- Supported customized cabinet.
- Optional color: black or white.
- High transparent rate, the highest can reach 70%.
- Slim cabinet, space saving; light weight, no need to change architectural structure,adapt to different installation place.
- Environmental Projection: no need air-con.
- Easy maintenance: fast replaced module, support front and rear service.
- Stacking, hanging and fixed installation are supported.
- GOB surface is for option, what can reach IP43 and lamp protected.

- According to the actual installation site situation and demand, can use 1000x1000(mm) or 500x500 (mm) size of the cabinet.

- Support Front or Service

Parameters:

Model	T-B3.9-7.8	T-B7.8-7.8	T-B5.2-10.4	T-B10.4-10.4
Pixel Pitch	W3.91mm-H7.82mm	7.82mm-7.82mm	W5.21mm-H10.42mm	10.42mm-10.42mm
Transparency Rate	60%	65%	65%	70%
Pixel Configuration	SMD1921	SMD1921	SMD2727	SMD2727
Pixel Density	32,768 pixels/m2	16,384pixels/m2	18,432 pixels/m2	9,216 pixels/m2
Panel Dimensions (mm)	500x1000 or 1000x1000	500x1000 or 1000x1000	500x1000 or 1000x1000	500x1000 or 1000x1000
Cabinet Resolution	256 x 128	128 x 128	192 x 96	96 x 96
Panel Material	Aluminum	Aluminum	Aluminum	Aluminum
Weight per Cabinet	12kg	12kg	12kg	12kg
Colors	281 trillion	281 trillion	281 trillion	281 trillion
Average Power Consumption	200 W /Sqm	200 W /Sqm	200 W /Sqm	200 W /Sqm
Max Power Consumption	500 W /Sqm	500 W /Sqm	500 W /Sqm	500 W /Sqm
Brightness	>2,000 nits	>2,000 nits	>2,000 nits	>2,000 nits
Refresh Rate	>3,840Hz	>3,840Hz	>3,840 Hz	>3,840 Hz
Servicing	Front/Rear	Front/Rear	Front/Rear	Front/Rear

Pictures:

Our Services

1. 20 Years professional led display manufacturer

2. Short delivery time: 5-15 working days, adjustable according to customer request
3. Wholesale price

4. OEM and ODM service
5. Customizable product upon request

6. 24/7 hrs online service
