Glass Window LED Mesh Screen Transparent LED Film Display LED Video
Wall
Film Type Self Adhesive Outdoor Glass Window LED Mesh Display
Application Of Outdoor Advertising Film Transparent LED Mesh Display
Advantages of LED transparent film screen:
(1) High transparency, 60% -95%, which can ensure the lighting
requirements and viewing angle range of the lighting structure,
such as the lighting range between the floor, glass curtain wall,
windows, etc., and ensure some lighting perspective functions of
the original glass curtain wall.
(2) Ultra-thin, does not take up space. The display thickness is
only 1 ~ 3mm, and the total weight is only 3.5Kg/㎡.
(3) that installation is convenient, a steel frame structure is not
need, and the glass curtain wall is directly fixed and attache, so
that a large amount of cost is saved.
(4) Novel and cool effect. The video image is suspended on the
glass curtain wall, which has good advertising effect and artistic
effect.
(5) that maintenance is convenient, the indoor maintenance is quick
and safe, and manpower and material resource are saved.
(6) energy conservation and environmental protection, the
traditional cooling system and the air conditioner are omitted, and
more than 40% of energy is saved compared with the traditional
screen energy conservation.
(7). Large viewing angle • Up, down, left and right viewing area up
to 160 degrees, no dead angle, no color cast, the image is always
perfect and seamless
Parameters:
| Model | T-G4 | T-G4-8 | T-G6 | T-G8 | T-G10 | T-G16 | T-G16-32 | T-G32 |
| Pixel Pitch | 4-4mm | 4-8mm | 6-6mm | 8-8mm | 10-10mm | 16-16mm | 16-32mm | 32-32mm |
| Transparency Rate | >80% | >80% | >80% | >80% | >85% | >85% | >90% | >90% |
| Module Size (mm) | 800X240 | 1000X240 | 1000X240 | 1000X240 | 1000X240 | 1000X240 | 1000X240 | 1000X240 |
| Module Resolution (dots) | 200X60 | 250X30 | 166X40 | 125X30 | 100X24 | 62X15 | 62X7 | 50X4 |
| Pixel Configuration | SMD1010 | SMD2121 |
| Pixel Density | 62,500 pixels/m2 | 31,250 pixels/m2 | 27,556 pixels/m2 | 15,625 pixels/m2 | 10,000 pixels/m2 | 3,844 pixels/m2 | 1,922 pixels/m2 | 961 pixels/m2 |
| Brightness | >3000 cd/sqm | >3000 cd/sqm | >3000 cd/sqm | >3500 cd/sqm | >3500 cd/sqm | >3500 cd/sqm | >2500cd /sqm | >1500cd /sqm |
| Weight | 3.5kg/sqm |
| Colors | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Average Power Consumption | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm | 200 W /Sqm |
| Max Power Consumption | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm | 600 W /Sqm |
| Refresh Rate | >3,840Hz | >3,840Hz | >3,840 Hz | >3,840 Hz | >3,840 Hz | >3,840 Hz | >3,840 Hz | >3,840 Hz |
| IP Rating | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% |
Different Size choosing
Pictures:
Our Services
1. 20 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to
customer request
3. Wholesale price
4. OEM and ODM service
5. Customizable product upon request
